Universal shaft

The universal coupling makes use of the characteristics of its mechanism, so that the two axes are not the same axis, there is an Angle between the axes can realize the continuous rotation of the connected two axes, and reliably transfer torque and motion.  Has a larger Angle compensation capacity, compact structure, high transmission efficiency.  Different structure type universal coupling two axis Angle is not the same, generally between 5°-45°.

Structure forms include cross shaft type, ball cage type, ball fork type, etc., the common material is 35CrMO forged steel, cross package 20CrMoTi, reasonable structure and excellent process, fully meet the advantages of buffering, damping and improving the dynamic performance of shafting.

Menowa Professional cardan shaft team can be connected to both ends of the installation form according to the size of the load required by the customer, the speed of the high and low;  Best scheme for making cardan axis.

Stable operation has a professional process, the structure is constantly optimized design bearing capacity of alternating torque increased by 30%

To ensure the overall coaxiality of 0.5mm;  More stable operation, critical speed up to 4000 RPM.  The unique sealing design inside the universal shaft can increase the service life of more than 11,000 hours by 25% with longer maintenance interval, saving cost for customers.

Menowa universal axis, the surface can resist high heat, high temperature radiation, corrosive medium and strong light damage, better anti-aging ability

Universal axis, the surface can resist high heat, high temperature radiation, corrosive medium and strong light damage, better anti-aging ability

Service scope of universal axis (common occasions)
